Web Services – Business Central Part- 1

You can use web services in Microsoft Dynamics 365 Business Central to expose data to the outside world.

You can use web services to get data from Microsoft Dynamics 365 Business Central and use it in other applications.

Any application, programing language or program that can work with XML and/or JSON for example: – Power BI, Microsoft PowerApps, a custom .NET program, etc. can connect to Microsoft Dynamics 365 Business Central fetch the available data.

A web service can also be used to create new or update existing data in the application.

Both XML (Extensible Markup Language) and JSON (JavaScript Object Notation) are open-standard file formats that are readable by humans. They are used to send information between clients over web services.

In this post we will discuss some terminology and differences between SOAP and OData. We will also learn on how to configure these services in Microsoft Dynamics 365 Business Central.

SOAP relies on HTTP(S), SMTP, FTP for message negotiation and transmission.

The most common type of messaging pattern in SOAP is the Remote Procedure Call (RPC), where one network node (the client) sends a request message to another node (the server), and the server sends a response message to the client. It uses SOAP envelope, which defines the message structure and how to process it.

A SOAP service exposes a WSDL (Web Services Description Language) file that describes how the service can be called, what parameters it expects and what data structure it returns. This file is an XML based document, and is targeted to be read by machines, not by humans.

OData (Open Data Protocol) is an open protocol that is designed to use and query RESTful APIs. An API (Application Programming Interface) is a set of routines and protocols that is used to communicate between different software components.

OData is built upon REST services and can be used to query REST services. By providing extra query parameters to a URL, you can for example limit or filter the result set.

SOAP exposes a WSDL document, OData exposes an EDMX document, which contains metadata for all the published web services.

You can see all the available OData web services by going to the search box and search for web services.  This page is used to enable access to OData and SOAP web services.

ws-001

OData web services can only be used with object types pages and queries, not with codeunits.  There are two versions of OData you can use, version 3 and version 4.  Version 4 is an enhanced version, and important to know is that version 4 returns JSON where version 3 returns AtomPub documents which are XML documents.

From this window you can add new or manage existing Web Services.

It is simple 2 Step task Add new object give service name and enable Publish checkbox. You will get your OData and/or SOAP URL.

For example: – object type page can be used in OData and in SOAP web services.

Let us explore the Web-Service Urls. For test purpose, I have created a Service with the name Customers for Page Customer Card.

https://ksd-Desktop:7748/BC130/ODataV4/Company(‘CRONUS%20International%20Ltd.’)/Customers

When we open, for example, our Customers web service, we can have a look at the URL.

First we have our server name and the port it’s using.  “https://ksd-Desktop:7748”

Then we have our instance name, which in our case is BC130.

Then our OData version, so version 4.  “ODataV4”

And then our company name, “Cronus International Ltd”.

And then finally our web service name, which is, in our case, “Customers”.

Let’s try this url, when we execute this url in our browser we get json file listing customers similar to below:


Here etag is the unique identifier of each records, it will be required when you update records, will discuss later.

If I remove my service name then:

https://ksd-desktop:7748/BC130/ODataV4/Company(‘CRONUS%20International%20Ltd.’)

{“@odata.context”:”https://ksd-desktop:7748/BC130/ODataV4/$metadata#Company/$entity”,”Name”:”CRONUS International Ltd.”,”Evaluation_Company”:false,”Display_Name”:”CRONUS International Ltd.”,”Id”:”ab76c7b4-3c72-4805-86f7-7d91a10612ce”,”Business_Profile_Id”:””}

If I remove my Company Name then:

https://ksd-desktop:7748/BC130/ODataV4/


If I open the metadata url

https://ksd-desktop:7748/BC130/ODataV4/$metadata

You will get EDMX file which shows metadata about the information in the OData web service.

ws-002

You can see some properties with our data types.  For example, if we scroll down, if we go to Customers, we have our entity type Customers, we can see some properties which our data types and max lengths.  We can also see what properties are primary key.  So this is number and so on.  So all useful information when you’re creating applications that use these OData web services.

Filtering the OData

You can set filter expression to the url few examples as below:

We will use the filter option top for limiting the result to top 5 records of customer.

After our service name, we type question mark, then the dollar sign, and then the word top equals 5.

For example :

https://ksd-desktop:7748/BC130/ODataV4/Company(‘CRONUS%20International%20Ltd.’)/Customers?$top=5

Now the query will result in only first 5 records for customer.

If we want to see next 5 records then we can append &$skip=5 on above url

https://ksd-desktop:7748/BC130/ODataV4/Company(‘CRONUS%20International%20Ltd.’)/Customers?$top=5&$skip=5

If you want to see specific customer you can modify url as:

https://ksd-desktop:7748/BC130/ODataV4/Company(‘CRONUS%20International%20Ltd.’)/Customers(‘10000’)

Please refer to EDMX file to find correct name of the fields if wants to filter on specific fields.

https://ksd-desktop:7748/BC130/ODataV4/Company(‘CRONUS%20International%20Ltd.’)/Customers(‘10000’)?$select=Name

You will get the result as below for above url query

“@odata.context”:”https://ksd-desktop:7748/BC130/ODataV4/$metadata#Company(‘CRONUS%20International%20Ltd.’)/Customers/$entity”,”@odata.etag”:”W/\”JzQ0O044eFNmcWdXV0NpYlhTZDhUdTlrdytZUmdQbWRkL2U4TzZ4UEsxNGtod0

E9MTswMDsn\””,”Name”:”The Cannon Group PLC”}

You can add other fields too by appending the url with ‘,’

Customers(‘10000’)?$select=Name,City,Address……………

As told earlier please refer to EDMX file for correct Fields Name or Property it is case sensitive.

You can remove the Primary Key from the url to get list of selected fields for all customers.

Customers?$select=Name,City,Address……………

https://ksd-desktop:7748/BC130/ODataV4/Company(‘CRONUS%20International%20Ltd.’)/Customers?$orderby=City&$select=Name,City,Address

You can use orderby to sort the data from other than Primary key, by default it is sorted by Primary Key.

You can use desc for descending sort.

https://ksd-desktop:7748/BC130/ODataV4/Company(‘CRONUS%20International%20Ltd.’)/Customers?$orderby=City desc&$select=Name,City,Address

You can use filter to filter specific field values as:

https://ksd-desktop:7748/BC130/ODataV4/Company(‘CRONUS%20International%20Ltd.’)/Customers?$filter=City eq ‘Zutphen’ or City eq ‘Atlanta’&$select=Name,City,Address

you will get output as:


You can use expressions like [filter=Balance_LCY gt 0] or [filter=Location_Filter eq ‘BLUE’] etc.

I stop here for today. We have seen how the Web Services OData can be used to query records.

We will discuss about other stuffs in our next post in more details.

Till then keep exploring and learning, see you in next post. Take Care of yourself.



Advertisements

Automated Testing in Business Central

Testing is the essential part of the software development process and Cover User Scenarios.

Developers take care of their unit tests and perhaps, some wider coverage when they deliver a finished module. When developer tests the software he only tests scenarios for which he have done development.

In manual testing, since there are usually only humans involved, there will without doubt be discrepancies in the burden that test are conducted. There’s is always the trade-off between whether or not to conduct a full test scenarios for every delivery. In most scenarios tests are performed to areas of application, those are relevant for the current release. Like why should you repeat the purchasing scenarios if you only made a change to the sales process for example?

Automated testing brings a level of insistency and repeatability to testing that is impossible to achieve with just humans. By using a tool that facilitates automated testing, you can run as many test, as many times, as you want with a guarantee that each and every test will run exactly the same way as the first time. You can actually prove that a change in the sales process will not affect the purchasing process.

The key to successful automated testing is that you can link test scenarios to user scenarios. To make your development process itself test-based, by writing proper test at the start of the development process will give you clear and concrete requirements that the software has to meet.

Repeatability of running test scenarios is another key ingredient of automated testing. Manual testing can be very tedious task that can cause a human tester to lose focus. Added project pressure can add to the temptation for tester to skip the unimportant pieces of the test scenarios. How many times do you have to make sure that you can’t enter text string in an amount field for example?

Automated testing is a predefined set of Instructions that always run, no matter what time, no matter how eager the project manager wants the results, no matter how hungry you are, the test scenario is defined and it will execute every instruction every time that the test runs.

It will run exactly the same manner each and every time. You can spin as many sessions you need and simulate real load test. You can potentially scale this up to hundreds or even thousands of users at the same time and really test the limits of your software’s capabilities. Even in larger organizations it will never be possible in a manual test situation.

Manual testing is great to prove that a new piece of software meets the requirements. But what is not always clear is whether a new change in the software has had any adverse effects on existing functionality in other areas. Whereas in case of automated testing provides the capability to prove that all test scenarios can still give you the same test results over time, whenever you make any changes to any part of the software. Since you can schedule automated tests, you can run a full system test overnight or weekend, when you come back at your desk in the next morning you can look at the outcome of the latest test run and focus on just the ones that failed.

Test that are included in the standard business central test toolkit, cover the entire application. You can run the full length of thousands of those test in a matter of hours. So, combined with a build script, you can automate the creation of a new tenant, implement your compiled app, run selected tests and then, evaluate the results in a fraction of the time, which it would take a team of manual testers to do the same thing in hours. Automated testing provides the capability to run a full test set every single day or multiple times a day. If you have that capability, why not use it?

You can organize your development process to include daily build process and include a full sweep of the entire set of tests, and almost guarantee a 100 percent success when you are ready to deliver your software.

Those working on AppSource apps, will not have a choice on matter. Automated testing is mandatory for your app source submission.

Conclusion best way to do testing will be take a fresh demo database of BC, install your app and test the user scenario. If you need to prepare any data is necessary to successfully complete the user scenarios or the test scenarios, the creation of that data should be part of the installation process of your app, and or your test app. Most important feature should be included is the ability to run them in a non-super role, it should not be mandatory to have super rights in order to use your app. Make sure you include the test for non-super users as well.

Oh!! Today lots of lecture. Let’s see how we can implement this, although writing test scripts is not a easy task, require lots of efforts to cover all scenarios and knowing the system well in advance, with clear set of inputs and outputs, else even you pass test scenario chances to fail in real word cannot be avoided.

Below are the steps we follow to create an automated test script. Below is not the full and final, it is just an idea how we can implement this, rest you have to use your experience and skills to complete as per your requirement and project need.

Not compulsory but it will be better if we can use fresh database for this task. We will have only our Extension on which we are going to run this Automated Test and the Extension which we are creating in this post for Auto Test.

Step – 1 : Nav/BC Preparation

If not already imported you need to import Set of objects to enable automated testing. You can find them on installation disk under TestToolKit folder.

tcu001

If creating a Docker Container use option –includeTestToolkit in the new NavContainer Cmdlet.

Once you are done now you can run your Test Tool

tcu002

tcu003

Hold on, we will come to this later in below post.

Step – 2 : VS Code Project Preparation

Create a New project, and add Folder Structure to arrange your files.

You can find steps in this post : Bare Minimum Steps to Start with fresh Extension Project for Business Central

We need to Specify test target as a dependency. For this it is compulsory to have the apps symbols file to make this work. Install your Extension on this database if not already deployed.

We need to import symbols for the Test Framework as well. So need to specify ‘test’ settings to the app.json file of this project. Specify minimum supported value e.g. 12.0.0.0

Once these two settings are done, now when you hit Download Symbols it will include the Symbols for your Extension and Test Toolkit Objects.

tcu004

Now you can see 2 additional package symbol files are downloaded.

  1. KSD Consultancy_MyFirstExtensionProject_1.0.0.0.app
  2. Microsoft_Test_13.0.24209.0.app

And 2 std. symbol file that gets included when you create any new Extension Project.

Step – 3 : Writing Test Codeunits

We will create a codeunit of Subtype = ‘Test

Test procedures are decorated with [Test] attribute

Your OnRun will execute first, followed by other all test procedures.

You can use [TransactionModel] attribute to specify each test procedure is in a separate database transaction.

The output will be Success or Failure.

Failure is any error that is raised by the test code or from the code which is being tested. In either case Other Test procedures will still continue.

Other Features are Test Pages and UI Handlers, we will discuss on same in some other similar post.

AssertError statement is like if I do this error should come, it happens then your test is Success. In this case Failure is actually Success as you knowingly created error.

As I told earlier also this is very complicated area, to write Test Scripts, but if you start practicing from small stuffs eventually you will learn and will able to write a good Test Scripts. You can check out other standard Test Codeunits and update your knowledge how you can write your own Test Scripts.

My sample Test Codeunit looks something like below, it is just for idea in real scenario there should be lots more.

tcu005

Step – 4 : Deploy & Run the Test App

Publish your Test App.

Go to Extension Management

tcu006

You will find 2 Extension, The Initial Extension which we created in earlier posts and the Extension we just deployed.

Now open the Test Toolkit Page – 130401

Click on Get Test Codeunits function then Select Test Codeunits

tcu007

Now Select the Codeunit we just created.

tcu008

You can select other Codeunits as per the requirement, in my case I am just going to select my Codeunit which we created in this post.

tcu009

This will list all the functions available in the Test Codeunit.

Now you can select Run all or Run Selected. To test your App, I will select Run All.

tcu010

Here is the final output of test result

tcu011

Hope you will agree the test we performed, same if done manually no one can test the same in 6 seconds as this did. And we can perform as many times, and any time.

Once your Test Codeunit in place whenever you make changes to app, you can just run the test and verify that any changes you made have not impacted the existing functionality in any manner.

To save the time in testing, you have to pay in other way in creating the test codeunit as it is not that easy to cover every user scenario in your test codeunit and will require lots of efforts.

But when you are working for App Source you have no choice, you will have to do it.

Today the post got bit longer, but this topic is very complicated and require explanation. Hope you got the starting point from this and will put your efforts to reach to your required conclusion, take help of existing codeunit, nothing will be better than those to learn how Microsoft themselves implements it.

See you again with some more topics, and if get some extra time will try to add more to this post as a second part to this post. Fact is one post is not sufficient for such a huge topic.

Till then keep exploring and learning and take care of yourself.

AL Basics – Part-1

Programming in AL is very easy, just we need to make up our mind to accept the changes. Till we resist to changes it seems to be hard once we accept it, that becomes easy.

In VS Code, for AL it provides Snippets which help you with creating your base structure following which you can easy build up your complex coding structures.

Few Snippets ready to use are as below:

To Create Structure of Snippet to use
Table ttable
Page tpage
Codeunit tcodeunit
Page Extension tpageext
Table Extension ttableext
Table Field tfield
Page Field tfieldpage
Trigger ttriger
Functions/Procedure tprocedure
Assert error tassert
With Do twithdo
If tif
If Else tifelse
Case of tcaseof
Case else tcaseelse
For tfor
While twhile
Repeat Until trepeat

Today I will explain on conditional and loop statements for others I will do in next post.

These statements are similar as we are familiar with using in our C/AL.

Below are few examples to explain them, since no changes so need not commentary for same.

conditional StatementsLoop Statements

For other Snippets will come in next post.

Quick Start with Extensions for Business Central

Today I am going to give you a tip for getting started with Extension Building for Business Central.

As AL have newly introduced so it is going to take time to learn and be comfortable with programming using AL codes.

Best way of learning anything is learning by examples. What if we first learn what will be equivalent to actions we perform in Navision designer.

So to demonstrate this I will start with creating a small customization directly in Navision then convert it to Extension.

Are you ready? Let’s start with this exciting journey of 1-2-3 step.

Step 1.

Saving my Base Line Object (Prior to performing any Modification).

In this example I am going to Modify Table – Item & Page Item Card.

Let’s export this two object as FOB, Later we will require this to revert our customization.

Also export this two objects as txt. This we will require in our Extension building process. But need to follow instructions explained in below step, else this file will be rejected by the tool when we try to convert to AL. Follow the process of exporting text file explained after completing the Customizations in Step 3.

Step 2.

I will create one Table 50000 – Product Range as below:

1

Next I will create one List Page on above Table, Page 50000 – Product Range as below:

2

Also will Add Table Property as below to enable Lookup & DrillDown

3

Save your objects.

Now I will add one field to Table Item & Page Item Card as below:

4

5

Now I am done with my all customization and saved my modified & New Objects.

Step 3.

Now we will export these objects All New & Modified into Text File.

But we will not do it from Object designer rather will do it from command prompt.

Preparing for AL Conversion.

Run Command Prompt as Administrator.

Change to RTC folder.

6

Check your folder where you have installed, default location is as one I am using.

You can export all objects in one single file or one file per object. I am exporting one object per file, you can explore command parameter to use accordingly.

I will be using below commands.

First we will create 4 Folders namely Original, Modified, Delta & Result

Note: Make sure ExportToNewSyntax with command parameter is used else txt2al (which we will use below) will reject your files, it is mandatory.

Below command is to export Original objects before modification: (Save in Original Folder)

1. finsql.exe Command=ExportToNewSyntax, File=G:\RND\Txt2ALTest\exportedBaselineObjectsT27.txt, Database=”Demo Database NAV (13-0)”, ServerName=”KSD-DESKTOP” ,Filter=Type=table;ID=27

2. finsql.exe Command=ExportToNewSyntax, File=G:\RND\Txt2ALTest\exportedBaselineObjectsP30.txt, Database=”Demo Database NAV (13-0)”, ServerName=”KSD-DESKTOP” ,Filter=Type=page;ID=30

Below command is for New Objects: (Save in Modified Folder)

3. finsql.exe Command=ExportToNewSyntax, File=G:\RND\Txt2ALTest\exportedNewObjectsT50000.txt, Database=”Demo Database NAV (13-0)”, ServerName=”KSD-DESKTOP” ,Filter=Type=table;ID=50000

4. finsql.exe Command=ExportToNewSyntax, File=G:\RND\Txt2ALTest\exportedNewObjectsP50000.txt, Database=”Demo Database NAV (13-0)”, ServerName=”KSD-DESKTOP” ,Filter=Type=page;ID=50000

Below command is for Modified Objects: (Save in Modified Folder)

5. finsql.exe Command=ExportToNewSyntax, File=G:\RND\Txt2ALTest\exportedModifiedObjectsT27.txt, Database=”Demo Database NAV (13-0)”, ServerName=”KSD-DESKTOP” ,Filter=Type=table;ID=27

6. finsql.exe Command=ExportToNewSyntax, File=G:\RND\Txt2ALTest\exportedModifiedObjectsP30.txt, Database=”Demo Database NAV (13-0)”, ServerName=”KSD-DESKTOP” ,Filter=Type=page;ID=30

Our Next step will be to create DELTA files.

Open Business Central Administration Shell

Import your Microsoft.Dynamics.Nav.Model.Tools Module using below syntax

import-module “C:\Program Files (x86)\Microsoft Dynamics 365 Business Central\130\RoleTailored Client\Microsoft.Dynamics.Nav.Model.Tools.psd1” -force –verb

Execute below Shell Command:

Compare-NAVApplicationObject -OriginalPath G:\RND\Txt2ALTest\Original\*.txt -ModifiedPath G:\RND\Txt2ALTest\Modified\*.txt -DeltaPath G:\RND\Txt2ALTest\DELTA\ -ExportToNewSyntax

7

After this process we will get our Delta files in Delta Folder, this will be input to our next command/tool.

Next we will convert Delta File to AL files.

On Command prompt used above run below command: (This is not Shell Window please make sure)

txt2al –source G:\RND\Txt2ALTest\DELTA\ –target G:\RND\Txt2ALTest\RESULT\

8

Here we will get our *.al files. Which will be used for creating extensions.

Step 4.

Perform clean up to the database.

  1. Import the FOB exported in Step one to restore your original Table 27 & Page 30.
  2. Delete New Created Objects.

Now our database in in original state as before performing customization.

Fresh and Clean Business Central Database without any customizations.

Step 5.

In this step we will create extension in VS Code using above obtained *.al file.

Open VS Code and Press <Ctrl>+<Shift>+<P> and select AL:Go! to create a project Folder

9

Enter your Project Folder and press enter

10

Update your app.json file as below:

Add Name & Publisher, also check available idRange all objects in this project must be in this Range.

11

Update your launch.json file with your server & authentication details accordingly:

12

Remove the HelloWorld.al file created by default by right click and select delete.

Now add your created *.al files

13

You can drag and Drop to your Project Folder.

Now you will get errors, to resolve it we need to download our Symbols from Navision.

To download press <Ctrl>+<Shift>+<P> to open command Pallet and select Al: Download Symbols

14

If your server settings in launch.jason is correct your Symbols will get downloaded.

15

Now let resolve any others errors that may have in your *.al Files.

First I will rename my all Files to meaningful name so that in future it is easy to manage.

To do so, right click the File and select Rename, in my case I have renamed as below:

16

Now we will open each file and perform required action to resolve the errors as below.

After changes don’t forget to save your files.

17

18

19

20

Ensure Object ID you use is within the range of id provided in app.json file. ID is not used in database or any other extensions. Else when you deploy the extension it will give errors, also make sure you give unique object names too.

DataClassification property is not available in Al so we removed it.

Now my all objects are error free, and ready to be packaged.

Step 6.

Now we will Deploy & Test our Extension.

To create a package press <Ctrl>+<Shift>+<P> to open command pallet.

21

You can choose AL:Publish also it will create package and Publish to the server.

Next you choose AL:Publish to deploy your Extension to the Business Central.

You can verify your Extension from Extension Management Page from Navision Client

22

Double click on your extension record to see details:

23

Now let’s see in action our extension.

Open Item Card.

24

Congrats, your First Extension is ready to use.

There is lots of many thing to explain, but in single post everything is not possible. I will come up with basic things and creating Extensions from scratch in some other posts.

It was just a quick idea, as everyone is looking option for upgrade so this information may be handy to plan their next move.

We will learn basics of AL and other fundamental things in our upcoming posts.

Before I close this post will like to share few more details to complete this post.

If you check your Navision you will not find any object or additional fields we added in our extension, then where is my data stored?

Let’s have look in SQL.

25

Item Extension & Product Group table is created with your app id of the extension.

We will discuss in more details about other things in details in our next upcoming posts.

Till then keep learning, and stay safe, take care.



Image Analysis feature in Dynamics NAV 2018

In Dynamics NAV 2018, the Image Analyzer extension uses the Computer Vision API to analyze images that are attached to contact persons and items.

For example, this is useful for items because it lets you build up a stockpile of metadata about what you sell and use it to fine-tune search results when someone is browsing your web shop.

Image Analyzer is free in Dynamics NAV, but there is a limit to the number of items that you can analyze during a certain period of time. By default, you can analyze 100 images per month.

After you enable the extension, Image Analyzer runs each time you import an image to an item or contact person. You will see the attributes, confidence level, and details right away, and can decide what to do with each attribute. If you imported images before you enabled the Image Analyzer extension, you must go to the item or contact cards and choose the Analyze Picture action.

Requirements

There are a few requirements for the images:

  • Image formats: JPEG, PNG, GIF, BMP
  • Maximum file size: Less than 4 MB
  • Image dimensions: Greater than 50 x 50 pixels

How to enable Image Analyzer

To enable the Image Analyzer extension, do one of the following:

Method-1 : Open an item or contact card. In the notification bar, choose Analyze Images, and then follow the steps in the assisted setup guide.



IA-1

This will launch Image Analyser assisted setup guide, follow the step.



IA-2

IA-3

IA-4

Once you are done It will import your image for Analysing.

IA-5



Method-2 : Access the Service Connections, and then choose Image Analysis Setup.

IA-5.1

Choose the Enable Image Analyzer check box, and then complete the steps in the assisted setup guide.

IA-5.2

For URL and Key follow these steps:

Click on Computer Vision API Documentation

IA-6

Click on Try Computer Vision API

IA-7

Select your API Computer Vision API and then Get API Key

IA-8

Agree to T & C select your Country/Region and then Next

IA-9

Sign-In with the preferred account sign-in method

IA-10

Once done you will land on page which will have your Endpoint URL and Key

You must add /analyze at the end of the API URI, if it isn’t already there.

IA-11

Enter your Endpoint URL and Key and close the window.

IA-12

Now you import your Image, or select Analyze Picture if already imported

IA-13

This will analyze the Image and provide you with the Attributes.

The Image Analyzer Attributes page displays the detected attributes, the confidence level, and other details about the attribute. Use the Action to perform options to specify what to do with the attribute.



This is how you enable and configure your Image Analyzer Service.



To see how many analyses you have left in the current period

You can view the number of analyses you’ve done, and how many you can still do, in the current period.

Enter Image Analyzer Setup, and then choose the related link.

The Limit type, Limit value, and Analyzes performed provide the usage information.



To stop using the Image Analyzer extension

Enter Service Connections, and then choose Image Analyzer Setup.

Clear the Enable Image Analyzer check box.



I will come with more details as I proceed.







NAV Development Preview – Modern Development Tools for Dynamics NAV

Dear friends, after writing blog on Modern Development Tools for Dynamics NAV few of my readers requested to compile all information related to this in single blog.

Here are the links related to these posts, not all are my but are useful and will help keep you updated on same.

Extensions 2.0

Configuring Visual Studio Code

Below are the helpful other links from Microsoft Dynamics NAV Team

How do I learn more?

Check out these docs:

Tools overview

Getting Started guide

Object overview and AL language changes

Modern Development Tools Updates

released from launch till Dec 2017

Modern Development Tools for Dynamics NAV

NAV Development Tools Preview – January Update

NAV Development Tools Preview – February Update

NAV Development Tools Preview – March Update

NAV Development Tools Preview – April Update

NAV Development Tools Preview – June Update

NAV Development Tools Preview – July Update

NAV Development Tools Preview – August Update

NAV Development Tools Preview – September Update

NAV Development Tools Preview – October Update

NAV Development Tools Preview – November Update

NAV Development Tools Preview – December Update

Hope you find this information useful in understanding and learning the new Modern Development Tool for Dynamics NAV 2018.















Extensions 2.0 – Dynamics Navision 2018

The issue with customizations is that they often introduce challenges when upgrading. It’s hard to upgrade a solution from one version to the next when changes have been made to the underlying solution. Extensions, and the new version – Extensions 2.0 – solves this problem.

Instead of defining customizations in the original source code, extensions are written alongside the solution source, where the integration with the source is handled with events. An extension can add new objects and extend existing objects that are present in the solution. The extension code is packaged in a file, which you can deploy to your solution. This allows us to upgrade the underlying solution and, as long as the events remain, the extension will behave in the same way from version to version.

To help you developing solutions for this new programming pattern, you can use the new developer tools to build, test, and deploy extensions.



In app designer

In the client, you can switch to the in app designer mode that provides a way for you change the look and feel of the client easily and quickly. In short, the in-client designer lets you define what elements (such as fields, groups) appear on a page and how they are arranged. The in-client designer also provides an interactive way to create extensions based on changes you make in the client. Some of the features include:

  • Adding a field from the source table to a page.
  • Moving a field to another place on a page.
  • Removing a field from a page.
  • Previewing your design in desktop, tablet, and phone clients.
  • Saving the changes for the tenant or saving as an extension package file in Visual Studio Code.
  • Changing the caption of a fields on the page.
  • Adding, moving, renaming, and removing an action.
  • Adding, moving, and removing page parts.
  • Adding new pages.



Personal and organizational design changes

As an end user, changes can be applied so that only the user who made the changes will see them. This enables users to personalize the pages for their role. Examples of personalization could include moving important fields to a more prominent position on the page, or renaming a date field so that it is clearer which field is the ship date versus the expected arrival date. Alternatively, as an administrator, changes can be made globally, so that everyone in the organization can see them.

Business consultants can also access the same tools to help customers make changes to their solution, resulting in improvements in productivity for all users. For example, they could add new actions to run custom reports, or introduce entirely new pages or page parts.



Working with the In App Designer

To turn on the In-App Designer, start the client as normal, and then simply choose the In-App designer icon in the ribbon on any page in the client.



ExtV2-1

The Design mode bar appears at the top page, indicating that the in-client designer is active. You can now open any page, and start making changes.

ExtV2-2

Choose More to display additional design options, such as adding a field, creating a new field, and changing the preview to another client type.

ExtV2-3



ExtV2-4

To move a field, click and hold the handle in the field to drag and drop it from its current position to the new location, as indicated by the horizontal line.

ExtV2-5

To remove a field, click the field’s handle, and then choose Remove.

ExtV2-6

To add a field, choose the Field button, and then drag and drop a field from the list that appears to the desired location.

ExtV2-7

To preview in another client type, simply choose one of the preview buttons.

When you are finished making changes, choose Stop Designing. You then have the option to save the changes to the tenant for all users, or to save the changes to a file that you can work on later in Visual Studio Code.

ExtV2-8

You can see that Extension is deployed on your solution, check as below.

ExtV2-9

Hope you will enjoy using this new feature of development.

Will come with more details as I proceed.

Configuring Visual Studio Code to Use Modern Development Environment with Dynamics NAV 2018

After installing Dynamics NAV 2018, I want to configure Visual Studio Code with Dynamics NAV to use new Development tool.

Before we start lets verify few things and update accordingly.

NDE-1

You can download VS Code from here:-Click to download Visual Studio Code

Install and Launch the Visual Studio Code.

Now Click View -> Extensions.

NDE-2

Click on … to open the extension menu.

Click on Install from VSIX

NDE-3

You can find VSIX file on the installation medium path:

“ModernDev\program files\Microsoft Dynamics NAV\110\Modern Development Environment”

or in the

“C:\Program Files (x86)\Microsoft Dynamics NAV\110\Modern Development Environment”

NDE-4

This will install AL Language Version 0.12.15355

NDE-5

Once the Extension installation is complete, follow below steps

Press Alt+A, Alt+L to trigger the Go! Command

NDE-6

Enter Project Name and Press Enter

NDE-7

Choose “Your own server”

Once you select the “Your own server” you will see a code like below in the “launch.json” file.

NDE-8

Update the information to look similar to below:-

NDE-9

I have updated my ServerInstance as DynamicsNAV110 (you check your instance name if changed while installing server)

I have updated my Authentication as Windows (I am using Windows authentication update what yours use accordingly)

I have added Port as 8049 (please check and use accordingly you are using the port, if using default 7049 then this step not required)

Now save your File. And Press <CTRL + F5>.

NDE-12

Enter your Credentials.

The server url and the web client url are assumed to be the same. That is not the case. The two settings we talked about above, the server url and the developer port number, are the only settings you need in the launch.json.

When VS Code publishes the extension to the NAV server, the NAV server returns the web client url as a response. This url is then opened in the browser. No setting needed in the launch.json at all.

The NAV server reads that setting from the Web Client Base Url server setting.

NDE-13

NDE-11

Your Extension is published, you can verify as below:

NDE-10

Now you are good to go with developing your Extensions using New Modern Development Tool using AL.

I hope this may have clarified your doubt on how VS Code and the NAV server work together!

I will come with more details as I proceed.

Microsoft Dynamics 365 – Overview

As we are aware of release of Dynamics 365 in November 2016.

Dynamics 365 for Financials is based on Project “Madeira” which was in public preview in the US and Canada since April 2016.

Dynamics 365 for Financials launched on November 1, 2016 in the United States and Canada, and intends to expand to additional countries in CY2017.

Dynamics 365 for Sales, Dynamics 365 for Marketing, and Dynamics 365 for Customer Service within the Business edition will also be optimized for SMB customers.

Microsoft Dynamics 365 for Financials, Business edition, has launched in the US and Canada! Microsoft Dynamics 365 for Financials is a business management solution that seamlessly connects people and processes.

It’s deeply integrated with Office 365 and includes built-in intelligence. With Microsoft Dynamics 365 for Financials, customers can easily connect their businesses; make better business decisions; and get started quickly, while easily managing growth. From day one, it makes ordering, selling, invoicing, and reporting easier and faster.

Dynamics 365 for Financials is only available as a SaaS offering from Microsoft.

Software as a service is a software licensing and delivery model in which software is licensed on a subscription basis and is centrally hosted. It is sometimes referred to as “on-demand software”. SaaS is typically accessed by users using a thin client via a web browser.

With intelligent business applications across CRM and ERP, Microsoft Dynamics 365 gives you choice.

Start with just what you need to run your business and delight your customers.

2-1

Say start with Financials.

And then add apps as your needs change.

2-2

In short evolve your business on your terms.

You can add more apps from AppSource as required for selected Products, Categories or Industries.

2-3

Each application solves real problems and delivers real value. But combine them and you get the power and possibilities to transform your business.

2-4

Dynamics 365 haves 2 Editions:

  • Enterprise
  • Business

Dynamics 365, Enterprise edition is optimized for organizations with 250+ employees.

Dynamics 365, Business edition is optimized for organizations with 10 – 250 employees.



Applications available in Business for:

Dynamics 365 for Financials is optimized to meet the needs of SMBs with roughly 10 – 250 employees.

These companies typically need more robust capabilities than the financial and accounting packages they started with, but are not yet ready to make a significant investment in highly customized ERP systems.

Dynamics 365 for Financials capabilities span financials management, reporting, fixed assets, supply chain and inventory management, contact/opportunity management, and project management. It also offers multi-company and multi-currency capabilities.



Applications available in Enterprise for:

  • Sales – Turn relationships into revenue with digital intelligence in each deal.
  • Customer Service – Earn customers for life with world-class customer service.
  • Field Service – Optimize your scheduling and use predictive tools to master the service call.
  • Project Service Automation – Create more profitable customer relationships using intelligent tools.
  • Operations – Make data-driven decisions for smarter, more efficient operations.

Other Applications:

  • Marketing – Deliver powerful customer experiences using Adobe Marketing Cloud.



Microsoft Dynamics 365 for Financials is an app in the Dynamics 365, Business edition. Additional apps within the Business edition (Dynamics 365 for Sales, Dynamics 365 for Marketing, and Dynamics 365 for Customer Service) are currently planned to be available in CY2017.



What is the difference between Microsoft Dynamics NAV and Microsoft Dynamics 365 for Financials?

Dynamics NAV is software, available via perpetual, subscription, and/ or SPLA licensing, that can be deployed on-premises or in the cloud and extended using Dynamics NAV Customizations or extensions.

Dynamics 365 for Financials is a new SaaS (cloud – only) service, available only via CSP, which can be extended via apps (validated extensions) in Microsoft AppSource.

Many of the capabilities available in Dynamics NAV will also be available in Dynamics 365 for Financials. However, they will be available in a way that is customer – ready out of the box, so these capabilities may surface differently in Financials than Dynamics NAV.

Microsoft Dynamics 365 for Financials is based on the Microsoft Dynamics NAV platform and several other Microsoft technologies.

It is not compulsory but for seamlessly experience Dynamics 365 for Financials from within Office 365, customers must have an Office 365 subscription that includes Exchange Online.

I will come up with more details in my up coming posts till then keep exploring and learning.







Microsoft Dynamics 365 for Financials

Areas covered and Features available in Dynamics 365 for Financials:

  • Bank & Payment Management
    • Bank Account Reconciliation
    • Check Writing
    • Electronic Payment
    • Reconciliation
  • Data Migrations
    • Lets you import your existing company data such as vendors, customers, and items from Excel or QuickBooks.
  • Financial Management
    • Account Payables
    • Account Receivables
    • Account Schedules
    • Budgets
    • Cash Flow Forecast
    • Deferrals
    • Fixed Assets
    • General Ledger
  • Inventory
    • Alternative Ship-To Addresses
    • Drop Shipments
    • Inventory
    • Item Substitutions
    • Non-stock Items
    • Returns and Cancellations
    • Shipping Agents
  • Office 365
    • Lets you manage business interactions with your customers and vendors, directly in Outlook.
  • Opportunity Management
    • Contact Management
    • Dynamics 365 Integration
    • Interaction/Document Management
    • Outlook Client Integration
  • Other Features
    • Change Log
    • Dimensions
    • Document Management, Capture & OCR
    • Multiple Currencies
    • Word Reporting
    • Workflow
  • Project Management
    • Basic Resources
    • Budgets/Estimates
    • Capacity Management
    • Jobs
  • Purchasing
    • Cross Reference
    • Purchase Invoice Discounts
    • Purchase Invoicing
    • Purchase Line Discounting
    • Purchase Order Management
    • Purchase Pricing
    • Salespeople/Purchasers
  • Sales
    • Pricing and Discounting
    • Sales Invoice Discounts
    • Sales Invoicing
    • Sales Order Management

Previous Older Entries

Important

Most of the contents you find in this blog will be either inherited from MSDN or Navision Developer IT Pro Help. Some places images are also directly taken from these sites. Purpose is simple to try those stuffs and re-produce adding few things as per my understanding to make easy understanding for others and quick reference.

Here nothing under my own brand or authorship of the content. At any point of time we are just promoting Microsoft stuffs nothing personnel with same.

Hope stuffs used here will not violate any copyright agreement with them. In case by mistake or in-intestinally it happens and the Microsoft feels these should not be used Microsoft have full right to inform me about same and will be glad to take down any such content which may be violating the norms.

Purpose is to promote Navision and share with community.

FB Profile

Like FB Page

%d bloggers like this:
